LPX12-5.4T2FR Leoch 12V 5.4Ah

LEOCH 12Volt 5.4Ah F2 FR (Flame Retardant) Sealed Lead Acid Battery

Physical Dimensions

• Nominal Voltage: 12V
• Nominal Capacity: 5.4Ah
• Terminal Type: F2 (0.250")
• Weight: 3.53 lbs
• Length: 90mm (3.54")
• Width: 70mm (2.76")
• Height: 101mm (3.98")
• Height over Terminal: 107mm (4.21")

Key Features

• Virgin lead plates with copper alloy terminal inserts for low resistance.
• Solid ABS jar and cover, with UL94V-0 Flame Retardant available.
• Strong gravity casted grids for long life.
• Designed for critical High Rate UPS Applications, offering a 5-7 year design life.
• Provides 100% initial capacity with COS & TTP welding for low resistance.
• UL recognized, IEC60896-21/22 certified, and IATA approved for Air Freight.

Applications

• Specifically designed for Small UPS OEM Enclosures with High Rate Loads.
• Ideal for High Power DC Back-up Supply systems.
• Perfect for Emergency Power Supply and Emergency Lighting.
• Suitable for 24-hour Banking Systems.
